Application manager RMM621

Produktbild av: Application manager RMM621

This product is no longer available.

Please check new generation in the section predecessor / successor or contact your local Endress+Hauser entity.

Funktioner och specifikationer

Tillbaka

Details

  • Mätprincip

    Process transmitter

  • Function

    Display

    Power

    Switch

    Isolate

    Convert

  • Certification

    UL rec. Comp

    CSA GP pending

    ATEX Ex i

    FM USA IS

    FM USA NI

    IECEx

  • Input

    6 x analog (U, I R, RTD, TC)

    18 x digital (PFM, Impulse)

  • Output

    3 x transmitter power supply

  • Relay output

    2...19 x NO contact

  • Auxiliary power supply / Loop power supply

    90...250 V AC

    20...28 V AC

    20...36 V DC

  • Dimensions (wxhxd)

    135 x 108 x 114 mm

    (5.32" x 4.25" x 4.49")

  • Software

    Mathematic function

    Logical function

    Data Logging

    Tele alarm

  • Operation

    8 keys

    interface RS232 / RS485 + ReadWin

  • Display

    Dot-Matrix LCD

    160 x 80 points

Dokumentation / manualer / programvara

  • Technical Information Application Manager RMM621

    Application Manager for decentralized process monitoring. Electronic
    recording, display, balancing, control, saving, event and alarm
    monitoring of analog and digital input signals.

    Teknisk information (TI)
  • Technical Information RMM621 Pump Control

    Multichannel pump control system for peripheral pump stations.

    Teknisk information (TI)
  • Additional Operating manual

    Memograph + RMM621
    Externe Kanalerweiterung
    External channel extension

    Bruksanvisning (BA)
  • RMx621/FML621 Profibus module

    PROFIBUS-Koppler DP-Slave module from Softwareversion V2.01.00
    Connecting the RMx621/FML621 to Profibus DP via the RS485 serial
    interface using the external module

    Bruksanvisning (BA)
  • Zusatzbetriebsanleitung/Addition Manuals Ethernet-Anbindung

    Zusatzbetriebsanleitung/Addition Manuals Ethernet-Anbindung
    Memo-/Eco-Graph

    Bruksanvisning (BA)
  • Operating Instructions pump manager

    Operating instructions Pump Manager

    Bruksanvisning (BA)
  • Operating Instructions RMM621

    RMM621 Application Manager, Operating Instructions

    Bruksanvisning (BA)
  • Operating Manuals ReadWin 2000 (GB)

    Operating Manuals ReadWin 2000

    Bruksanvisning (BA)
  • Modem connection

    Memograph, Memograph S, Memograph M, Ecograph T + RMM621
    Modem-Verbindung über RS232 Kabel / Modem connection via RS232

    Bruksanvisning (BA)
  • Appendix to operating instructions RMx621

    Energy Manager and Application Manager RMx621 with ModBus Interface
    V3.03.00.
    Connecting the Energy/Application Manager to ModBus-IDA-systems

    Bruksanvisning (BA)
  • Brief Operating Instructions RMM621

    RMM621 Application Manager, Kurzanleitung - Brief Operating Instructions

    Short Instruction (KA)
    07/07
    Tyska , Engelska , Spanska , fr , Italienska , Holländska
  • Flow and Energy Manager, Density controller ATEX II (1)GD Safety Instructions

    Safety instructions for electrical apparatus certified for use in
    explosion-hazardous areas.

    Ex Säkerhetsinstruktioner (XA)
  • Control Drawing FM RMC621, RMM621, FML621

    Flow and Energy Manager RMC621, Application Manager RMM621 and Density
    Calculator FML621
    Installation Notes for Hazardous Locations

    Certifikat FM / CSA (ZD)
  • Control Drawing CSA RMC621, RMM621, FML621

    Flow and Energy manager RMC621, Application Manager RMM621 and Density
    Calculator FML621
    Installation Notes for hazardous locations

    Certifikat FM / CSA (ZD)
  • Komponenty Systemów kontrolno-pomiarowych

    Wskaźniki panelowe i obiektowe, zasilacze, bariery,
    przetworniki sygnałów procesowych, ograniczniki przepięć
    oraz przemysłowe liczniki ciepła i przepływu.

    Verksamhetsområden (FA)
    03/10
    Polska
  • Zeller+Gmelin, Exakte Abrechung der energiekosten

    Um den Dampfverbrauch zu ermitteln, sollten die Leitungen mit genauer
    Messtechnik bestückt werden. Dabei bestand die Anforderung, eine
    hohe Messgenauigkeit bei einer grossen Messdynamik von 50 kg/h bis
    etwa 12.000 kg/h zu erzielen. Grund ist, dass die benötigten
    Dampfmengen je nach Jahreszeit und Produktionsauslastung sehr stark
    schwanken können.

    Fallstudier (CS)
    09/10
    Tyska
  • Pump manager RMM621

    Pump manager for pump and rain overflow basin applications used for
    water and wastewater

    Anbudstext
    09/06
    us
  • Application manager RMM621

    Application manager can be used for calculating, regulating and data
    recording in all industries.

    Anbudstext
    09/06
    us
  • contactors / transmitters

    Produktkod: FML621-, RMC621-, RMM621-
    Deklarationsnummer: EC_00167_01.16

    EU Declaration
    Tyska , Engelska , fr
  • Controller, contactors / transmitters

    Produktkod: FML621-, RMC621-, RMM621-
    Region: International (IECEx)
    Certifieringsorgan: PTB
    Skydd: [Ex ia] IIC

    Explosion Protection
    Engelska
  • contactors / transmitters

    Produktkod: RMM621-, RMC621-, FML621-
    Region: USA
    Certifieringsorgan: FM
    Kategori: I,II,III/1,2/ABCDEFG
    Skydd: ANI, AIS

    Explosion Protection
    Engelska
  • contactors / transmitters

    Produktkod: RMC621-, RMM621-, FML621-
    Region: USA, Canada
    Certifieringsorgan: CSA
    Kategori: I,II,III/ABCDEFG
    Skydd: [Ex ia] IIC

    Explosion Protection
    Engelska
  • contactors / transmitters

    Produktkod: RMM621-, RMC621-, FML621-
    Region: Europe (ATEX)
    Certifieringsorgan: PTB
    Kategori: II(1)GD
    Skydd: [Ex ia] IIC

    Explosion Protection
    Tyska , Engelska
  • contactors / transmitters

    Produktkod: RMC621-, RMM621-, RMS621-
    Region: Russia
    Certifieringsorgan: Rosstandart
    Godkännande, Nr.: DE.C.32.004.A_31290

    Metrology
    Ryska
  • contactors / transmitters

    Produktkod: RMC621-, RMM621-, RMS621-
    Region: Ukrain
    Certifieringsorgan: SE Ukrmetrteststandard
    Godkännande, Nr.: UA-MI/1P-1735-2012

    Metrology
    Ryska

Tillbehör / reservdelar

Nr
Order code
Specification
    • Order code 71402350

      Set, 10x fixing lever housing

      for RMA42x/RMx621/RTA421/RN221N/TMT12x

  • 7
  • 8
    • Nr 8 Order code 51004062

      Terminal plug-in 4pol.SMSTB2,5 91/92/53/

      Relay terminal/loop power

  • 10
    • Nr 10 Order code 51004063

      Terminal plug-in 4pol.SMSTB2,5 82/81/10/

      Analog terminal 1 (PFM/pulse/analog/loop power)

  • 9
    • Nr 9 Order code 51004064

      Terminal plug-in 4pol.SMSTB2,5 83/81/110

      Analog terminal 2 (PFM/pulse/analog/loop power)

  • 11
    • Nr 11 Order code 51004065

      Terminal plug-in 4pol.SMSTB2,5 104..101

      Terminal RS485

  • 12
    • Nr 12 Order code 51004066

      Terminal plug-in 4pol.SMSTB2,5 134..131

      Output terminal (analog/pulse)

  • 16
    • Nr 16 Order code 51004907

      Terminal RMx621/FML621, Input 1, RTD

      Pt100/Pt500/Pt1000, gray

  • 17
    • Nr 17 Order code 51004908

      Terminal RMx/FML621, Input 2, RTD

      Pt100/Pt500/Pt1000, gray

  • 19
    • Nr 19 Order code 51004909

      Terminal RMx/FML621, Input 2, 4-20mA

      PFM, pulse, loop power, gray

  • 18
    • Nr 18 Order code 51004910

      Terminal RMx/FML621, Input 1, 4-20mA

      PFM, pulse, loop power, gray

  • 15
  • 13
  • 19
    • Nr 19 Order code 51005953

      Terminal Ex RMx/FML621, Input2, 4-20mA

      PFM, pulse, loop power, blue

  • 9
    • Nr 9 Order code 51005954

      Terminal Ex 4pol.SMSTB2,5 83/81/110/11

      Analog terminal 2 (PFM/pulse/analog/loop power)

  • 10
    • Nr 10 Order code 51005957

      Terminal Ex 4pol.SMSTB2,5 82/81/10/11

      Analog terminal 1 (PFM/pulse/analog/loop power)

  • 16
    • Nr 16 Order code 51005958

      Terminal Ex RMx/FML621, Input 1, RTD

      Pt100/Pt500/Pt1000, blue

  • 18
    • Nr 18 Order code 51005959

      Terminal Ex RMx/FML621, Input 1, 4-20mA

      PFM, pulse, loop power, blue

  • 17
    • Nr 17 Order code 51005960

      Terminal Ex RMx/FML621, Input 2, RTD

      Pt100/Pt500/Pt1000, blue

  • 15
  • 18
  • 19
  • 13
  • 14
  • 18
  • 19
