Tankvision
Inventory management
Professional NXA85

Tankvision Professional NXA85 ©Endress+Hauser

Gathers data from connected interface modules (Tankvision Tank Scanner or Multi Scan)

Tankvision Professional is a software which can manage data from the field. The parameters are forwarded via Tankvision Tank Scanner, Tankvision Multi Scan and even PLC or DCS systems via open standards such as Modbus and OPC DA Client. Tankvision is based on a distributed architecture on a local area network (LAN). Due to its modular structure it is ideally suited for tank farms as well as large refineries with hundreds of tanks.

  • Fördelar

    • Single access point for up to 400 tanks on one system

    • Step-by-step site upgrade

    • Best fit visualization

    • Precise inventory

    • Simplified site approval procedures

  • Applikationsområde

    • Summarizes data from various Tank Scanners NXA820, Multi Scans NXA83 or host systems (such as PLC or PCS) via Modbus and performs tank calculations

    • Suited for tank farms as well as large refineries with hundreds of tanks

    • Approved for custody transfer...

Funktioner och specifikationer

Tillbaka

Details

  • Mätprincip

    Level radar

  • Function

    Tankvision Professional Software is specifically designed for operations of bulk storage facilities, marketing terminals, refineries and pipelines. It is designed to handle all the data acquisition, supervisory control and monitoring required in a single fully integrated solution.

  • Configuration

    Client and Server Software:

    Windows 7 (32 or 64 bit)

    Windows Server 2008 R2


    Server Software:

    Windows Server 2012 and 2012 R2

  • Mätprincip

    Level radar

  • Application Task

    Data acquisition

    Data management

    Process monitoring & visualization

  • Field of Application

    Tankvision Professional Software is specifically designed for operations of bulk storage facilities, marketing terminals, refineries and pipelines. It is designed to handle all the data acquisition, supervisory control and monitoring required in a single fully integrated solution.

  • Operating systems

    Client and Server Software:

    Windows 7 (32 or 64 bit)

    Windows Server 2008 R2


    Server Software:

    Windows Server 2012 and 2012 R2
